To better understand our Inflatek Valve, take a look at these cut-away views.
Key Features:
• Inflatable seal is available in all kinds of polymers to suit an array of materials ranging from abrasive dusts to food products.
• The design of the seal self-compensates the valve while in use from friction.
Whether the material is flowing into a void or sits static in a column, the valve is intended to cut through and provide an air tight seal.
• Valve has one moving part with a lubricated for life bearing and designed for low-maintenance. Replacement can be performed within an hour.
• Tungsten Carbide or Teflon shell are offered for those whose materials are abrasive or cohesive.
• Capable of maintaining a seal in 100% vacuum or even when there is a vacuum on one side of the valve and positive pressure on the other.
